Aiko 1 Ton 1.5M Winch Stacker for Open Pallet | Model : PT-WS100
Features :
- Compact and service free design.
- Unique design of winch for easier and safety lifting.
- Heavy duty “C” section mast.
- Adjustable fork width from 160mm to 690mm(WS25, WS50).
- Two parking brakes on steering wheels.
Specifications :
- Model : WS100
- Capacity : 1000 kg
- Load Center : 575 mm
- Max. Fork Height : 1500 mm
- Lowered. Fork Height : 88 mm
- Fork Adjust Width : 540 mm (Fixed)
- Fork Width : 160 mm
- Fork Length : 1150 mm
- Effort Force to Rated Load : 100 mm
- Lifting Height per stroke : 9.5 mm
- Ground Clearance : 24 mm
- Min. Turning Radius (outside) : 1250 mm
- Front Load Roller : Φ80 x 94 mm
- Steering Wheel : Φ150 x 50 mm
- Overall size (LxWxH) : 1600 x 725 x 1930 mm
- Net Weight : 182 kg
*Please take note only for open pallet
